Re: Camshaft Timing

Post by Gregstv » Sat Oct 10, 2020 6:58 am

Got the pins out. Connectors look clean. I am thinking i have more breaks in the harness further in. Might be time to get out the scalpel and start cutting it back.
Also getting a lot of no comms from ECU messages

User avatar
Shoppinit
Cruising
Posts: 20285
Joined: Wed Dec 31, 2008 6:24 pm

Re: Camshaft Timing

Post by Shoppinit » Sat Oct 10, 2020 7:43 am

That’s weird. Really hard to believe that there’s an issue in the middle of the harness.

Maybe you’ve got a module that’s faulting and taking down the CAN line.

Are the comms faults consistent? What exactly is the DTC?
Daytona RS6 C5 Avant. Viper'd, Billies, Waggers, MTM box brain, C6 stoppers, xcarlink, R8 coolant cap (woohoo)
///M3 E46 | XC90 (V8, natch) | Passat GTE | RR Classic V8 flapper
"The major difference between a thing that might go wrong and a thing that cannot possibly go wrong is that when a thing that cannot possibly go wrong goes wrong it usually turns out to be impossible to get at and repair."

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Sat Oct 10, 2020 7:54 am

I will copy them next round. If I move the harness I often get terminal 30 missing or intermittent. Other one is no communication with ECU. The strange one is I can't change the tune.

Mɐʇʇ
Cruising
Posts: 2724
Joined: Tue Oct 07, 2014 8:30 pm

Re: Camshaft Timing

Post by Mɐʇʇ » Sat Oct 10, 2020 10:49 am

In my mazda, a shorted injector was taking out the ABS module. different issues going on here, but makes shopps point that a completely unrelated problem was raising all sorts of other errors.
"not a professional engineer, mechanic and mechanist"

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Sat Oct 10, 2020 10:53 am

Yeah, it's going to take some finding. Will have a look tomorrow at the harness. I have 2 spare engines, both with harnesses. They need some work but maybe worth a change to rule it out. The only things I don't have a spare of are the ABS module and the transmission.

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Sat Oct 10, 2020 11:06 am

Thinking about what Shop said. The fault code it's always had is no communication with the radio. The TCM is not fitted and it has an aftermarket head unit. This may affect the K line. I have only ever done auto scans, so maybe going in and looking at measuring blocks is confusing the ECU. Might have to fit the Tragic Control Module. Any thoughts on this?
Really appreciate your help guys.

User avatar
Shoppinit
Cruising
Posts: 20285
Joined: Wed Dec 31, 2008 6:24 pm

Re: Camshaft Timing

Post by Shoppinit » Sat Oct 10, 2020 12:41 pm

I don't think that's going to be the source of your problem. If the radio's not there it's normal that it can't communicate with it. I'd be more concerned about a present module on the bus that's causing your ECU comms problems. Unless the only comms problem you have is the radio in which case you can safely ignore it.

I'd be most concerned about problems on the CAN Hi line like ABS module, Trans, etc.
Daytona RS6 C5 Avant. Viper'd, Billies, Waggers, MTM box brain, C6 stoppers, xcarlink, R8 coolant cap (woohoo)
///M3 E46 | XC90 (V8, natch) | Passat GTE | RR Classic V8 flapper
"The major difference between a thing that might go wrong and a thing that cannot possibly go wrong is that when a thing that cannot possibly go wrong goes wrong it usually turns out to be impossible to get at and repair."

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Sat Oct 10, 2020 10:53 pm

I have a spare TCU. I will give it a try.

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Sun Oct 11, 2020 12:19 am

Hooked up the battery and went for a drive. No issues no MIL. Been taking notes and the common thing is it's all good unless I access the ECU (01) directly using VCDS.
Then all goes to <beep>. I might just drive it for the week and see how everything goes.

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Mon Oct 12, 2020 2:33 am

Shop,
Have you heard of any issues using the USB Ross tech cable on the C5?

User avatar
Shoppinit
Cruising
Posts: 20285
Joined: Wed Dec 31, 2008 6:24 pm

Re: Camshaft Timing

Post by Shoppinit » Mon Oct 12, 2020 7:46 am

Not the kind of issues you're experiencing. My cable won't talk to my HVAC 95% of the time.

Can you try another cable? Anyone local to you?

You could also try changing the communication parameters in VCDS.
Daytona RS6 C5 Avant. Viper'd, Billies, Waggers, MTM box brain, C6 stoppers, xcarlink, R8 coolant cap (woohoo)
///M3 E46 | XC90 (V8, natch) | Passat GTE | RR Classic V8 flapper
"The major difference between a thing that might go wrong and a thing that cannot possibly go wrong is that when a thing that cannot possibly go wrong goes wrong it usually turns out to be impossible to get at and repair."

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Mon Oct 12, 2020 9:43 am

I won't to catch up with Tony in the next few weeks. I will see if he minds trying his lead.
I also have a Chinese Ross Tech nock off. It doesn't see all the modules.

User avatar
Shoppinit
Cruising
Posts: 20285
Joined: Wed Dec 31, 2008 6:24 pm

Re: Camshaft Timing

Post by Shoppinit » Mon Oct 12, 2020 9:44 am

Does the Chinese lead cause the ECU to fault?

And what is the ECU fault exactly?
Daytona RS6 C5 Avant. Viper'd, Billies, Waggers, MTM box brain, C6 stoppers, xcarlink, R8 coolant cap (woohoo)
///M3 E46 | XC90 (V8, natch) | Passat GTE | RR Classic V8 flapper
"The major difference between a thing that might go wrong and a thing that cannot possibly go wrong is that when a thing that cannot possibly go wrong goes wrong it usually turns out to be impossible to get at and repair."

Gregstv
3rd Gear
Posts: 273
Joined: Tue Oct 03, 2017 11:35 am

Re: Camshaft Timing

Post by Gregstv » Mon Oct 12, 2020 9:57 am

I will run it again. No fault from memory. Been a couple of years since I used it.

User avatar
IchBautAuto
4th Gear
Posts: 618
Joined: Thu Feb 20, 2014 11:23 pm
Location: Australia

Re: Camshaft Timing

Post by IchBautAuto » Mon Oct 12, 2020 9:59 am

Gregstv wrote:
Mon Oct 12, 2020 9:43 am
I won't to catch up with Tony in the next few weeks. I will see if he minds trying his lead.
I also have a Chinese Ross Tech nock off. It doesn't see all the modules.
Hi Mate,
Here in quiet Coolamon. No problems trying with my lead. Anytime. I'll be home Thursday or Friday and then there for some time I expect. Used a full tank today touring around. A mix of metal Art
and Sheep.
C5 RS6, Milltek and Wagners: B5 RS4 450 + HP: A4 1.8 GP TQS original: 1963 UNIMOG 404:
