Had another look over the weekend , split the joint that feeds pins 54+55 , identified the F125 feed and rejointed the cables with a new direct fused feed , went for a drive and unfirtunately got the same error , couldnt find the T17m connector yet. One thing I noted is that the feed from 54+55 must...

It was the T17m connector I was trying to identify , do I just follow the TCU lom to under the dash? im getting back on it tonight ,I have seen the two black wires going to pins 55+54 , they are joined together just before the TCU conector with another 2 black wires with a metal crimp with a rubber ...

Update Cleaned the TCU PCB and the connector pins with my graphite pencil Even depinned any connectors from the plug that had corrosion and cleaned them pin.jpg Refitted the TCU nad went for a drive Gearbox was faultless , before this reverse would be very temprementle and would work 1 in 5 times , ...

20250625_143444.jpg As if by magic ,passenger well ,bone dry ,drivers side foot well ,soaking wet ,water poured out of plastic box that TCM sits in , think I was just in time ,I can see where a power cable has been arching to enclosure which I think was throwing the short to ground code. 20250625_1...

Thanks for the replys gents , it happens all the time now , it was sporadic the first few days , will get the carpet up and check the TCU first then move to checking wiring.WIll report back if I find anything.

Gearbox has started to ping up the solid red gear indicator in the cluster , just plugged in and retrieved this code 18155 - transmission solenoid power relay P1747 35-00 open or short circuit to ground No engine codes or abs codes Cant seem to find much info regarding whether it's in the mechatroni...

https://www.ebay.co.uk/itm/387854661328?

link to audi unit from A6 , think its the same but check part number against RS6 unit

See post below

viewtopic.php?t=133768

Just read the advert properly , I see you have the 4 original springs , would you sell the springs on there own ?????

Do you have the 4 original springs , I can only see 3 in the pic????????

Superron has just released a video on YouTube which involves removing the engine from an RS6 for some work ,decent detailed vid if you are looking at taking the engine out yourself.

https://youtu.be/-w-GWiXapAI?si=iyTeXME8FfKFHgoQ

I had bad vibration through the pedals ,this combined with the h&r coilovers made for a terrible ride ,done the zip tie upgrade today to the pedal box and there is a massive difference driving the car now ,every vibration came through the pedals which made me think my suspension arms were knackered ...

Think I have driver's side cover as I replaced my driver's side complete head.
Let me know if you still need it

Hello , while I was under the bonnet last night I had a look and I think its the connector the black exhaust gas temp unit , theres two small boxes fixed to bulkhead just by the loom , one brown and one black , i think its for the black one as the brown one has a brown coloured plug. [attachment=0]r...
